TBE Multiform Series

Representing the first machine series produced by TBE, the TBE Multiform Series can be used to manufacture virtually all component parts across all sectors. This machine series and its tooling range is particularly suited to special projects where components require complex secondary operations and special operations including heading and chamfering.

Key Characteristics

  • 8 Servo Axes Standard – Optional up to 16 Axes; and as required.
  • On-Board Program Storage
  • Independent Eyelet Station
  • Servo Index Unit For 3-D Rotation
  • Automatic Component Rotation for Multi Plane Bends
  • Modular Tooling – Rapid Change Over Times
  • Integrated Decoiler
  • Full Diagnostic and Fail Safe Systems
  • Touch Screen Programming Controls – Allen-Bradley®

Optional Additions

  • Combined Straightening System: 2– Axis Synchronised Spinner Straightener
  • Conveyor System for packing Wire Forms
  • Double Torsion Coiler
  • Various In-Line Heat Treatments
  • Welded Assemblies
  • Chamfering; Threading; Torsion Coiling and Heading Operations
  • Simultaneous Production of two or more Wire Forms
  • Feeder Encoder System
  • Press Stations: 12.5 – 150 Tonnes
